Details and Specification
Details
Technical Specifications
Frame Hi-Tensile Steel with Chromoly Down Tube, Mid BB, Internal Headset
Top Tube Size: 20.5?
Fork Chromoly Steerer Tube with Hi-tensile steel Tapered legs, 3/8" dropouts
Fork Rake: 28mm
Handlebars Hi-Ten 8.5"
Upsweep/Backsweep 12?/1?
Grips Riblet Grips
Seatpost Steel
Saddle Medium Width Seat/ Post Combo
Pedals Atom Plastic Pedal with 9/16" Axle
Brakes Rear u-Brake, Forged Alloy, Wide Body, Clear Brake Pads
Brake Levers Forged Alloy Lever
Stem Forged Alloy Top Load Stem
Freewheel 9 Tooth Driver with Hub
Chainwheel & Cranks Phorcys, Cold Hard Steel, 25T
3-Piece, Tubular Heat-Treated Chromoly, Bolt for Sprocket, Pinch Bolt with 8-Splined Spindle, 170mm 28.6mm Round Arm
Headset Integrated 45°X45° Sealed Cartridge Bearing
Chain KMC Z510 1/2 x 1/8
Bottom Bracket American Ball Bearing
Front Hub Loose Ball, Forged Alloy Shell, Drilled for 36 Spokes, 3/8" Chromoly Axle
Rear Hub Sealed Bearings, Forged Alloy Shell Drilled for 36 Spokes, 14mm Chromoly Axle
Spokes 14 Gauge with Brass Nipples
Tyres 20 x 2.4
Rims Alloy, Single Wall, Drilled for 36 Spokes (20")
Bell N/A
Warranty
Lifetime warranty on Frame and Fork
12 Months Manufacturer's Warranty on all non-consumable components
12 Months Manufacturer's Warranty on all electrical components, such as motors, display or batteries.
Consumable parts (including grips, tubes, tyres, cables, brake pads, saddle coverings, chain, spokes, cassettes and chain rings) are not covered by the warranty.
